PADUA SURFACES
FORMATS & TECHNICAL DATA
Every field size, the complete mosaic shape program, and the technical and packing specifications that apply across the Padua porcelain line.
AVAILABLE SIZE
Field Formats
Formats produced across the Padua line. Individual collections carry a subset — the collections carrying each size are linked below.
3"×24"
Bullnose / skirting
4"×12"
12"×12"
12"×24"
24"×24"
12"×48"
24"×48"
Standard thickness is 9 mm; Monza, Motley, Ceppo, Metal Max and River Wood run thicker (9.2–10 mm) and Berna runs thinner (8.5 mm) — see each collection page.
MOSAIC SHAPES
The Mosaic Program
Padua produces mosaics in 31 shape and size combinations. Availability varies by collection — most collections offer a matching hexagon mosaic. Ask our team about a specific shape in a specific colorway.
HEXAGON
8 options
- 1"294 × 298 mm
- 2"301 × 298 mm
- 3"260 × 300 mm
- 4"300 × 262 mm
- 4"Cluster layout348 × 130 mm
- 6"258 × 298 mm
- 8"198 × 198 mm
- 10"260 × 260 mm
SQUARE
6 options
- 2"300 × 300 mm
- 3"300 × 300 mm
- 4"300 × 300 mm
- 5"118 × 118 mm
- 6"148 × 148 mm
- 8"198 × 198 mm
HERRINGBONE
2 options
- 1"×3"211 × 211 mm
- 2"×6"283 × 305 mm
TRAPEZIUM
2 options
- 2"×2"×4"299 × 346 mm
- Trapezium + Triangle 2"×2" / 2"×4"305 × 235 mm
CHEVRON
4 options
- 6"×2.5"205 × 208 mm
- 3"×0.2"×5"255 × 222 mm
- 4"×2"458 × 162 mm
- 6"×0.5"×3"504 × 286 mm
OTHER SHAPES
9 options
- Piazza Multi size300 × 300 mm
- Parallelogram 3"With golden metal304 × 360 mm
- Basketwave 2"×2"300 × 300 mm
- Rhombus 2"346 × 300 mm
- Leaf 2"296 × 343 mm
- Diamond 2"290 × 300 mm
- Pickets 2"×6"310 × 254 mm
- Rectangle 2"×4"300 × 300 mm
- Bricks 1"×3"285 × 311 mm
Dimensions shown are sheet sizes.
TECHNICAL SPECIFICATIONS
Performance
Tested to EN ISO 10545 methods. Values apply across the Padua porcelain line.
| TECHNICAL CHARACTERISTIC | TEST METHOD | PRESCRIBED | PADUA VALUE |
|---|---|---|---|
| MEASUREMENT & SURFACE APPEARANCE | |||
| Length | EN ISO 10545-2 | ±0.6% | ±0.1% |
| Width | EN ISO 10545-2 | ±0.6% | ±0.1% |
| Thickness | EN ISO 10545-2 | ±5% | ±1% |
| Rectangularity | EN ISO 10545-2 | ±0.5% | ±0.1% |
| PHYSICAL PROPERTIES | |||
| Water absorption | EN ISO 10545-3 | ≤ 0.5% | ≤ 0.1% |
| Breaking strength | EN ISO 10545-4 | ≥ 1300 N | ≥ 1300 N |
| Modulus of rupture | EN ISO 10545-4 | — | ≥ 35 N/mm² |
| Resistance to abrasion | EN ISO 10545-7 | — | PEI Class 3 |
| Slip resistanceOil-wet inclining platform test (matte) | AS 4586-2013 / AMDT 1-2017 Appendix D | N/A | R9 |
| DCOF, matte finish | ANSI A326.3 | — | > 0.42 |
| MOHS surface hardness | 5–8 | ||
| CHEMICAL PROPERTIES | |||
| Resistance to chemicalsHousehold chemicals and swimming pool salts | EN ISO 10545-13 | Minimum GB | Pass |
| Resistance to staining | EN ISO 10545-14 (when subjected to chemicals) | Minimum Class 3 | Pass |
PACKING SPECIFICATIONS
Carton & Pallet Data
| SIZE | PCS/CTN | SF/CTN | SF/PLT | CTN/PLT | LBS/PALLET |
|---|---|---|---|---|---|
| 12"×24" | 8 | 15.5 | 620 | 40 | 2,734 |
| 24"×24" | 4 | 15.5 | 620 | 40 | 2,734 |
| 8"×48" | 6 | 15.5 | 558 | 36 | 2,381 |
| 9"×48" | 5 | 14.85 | 713 | 48 | 2,943 |
| 24"×48" | 2 | 15.5 | 465 | 30 | 2,248 |
| Hexagon 12"×12.5" | 11 | 11 | 594 | 54 | 2,612 |
Figures from the manufacturer’s packing lists; the 9″×48″ row is converted from metric. Confirm current carton and pallet quantities with our team before ordering.
